2025 Pitts LB55-22DC 53x102 Tri Axle Steel Lowboy Trailer - Air Ride, Fixed Axle

2025 PITTS LB55-22DC HYDRAULIC DETACHABLE GOOSENECK

***Available in 51 Ton & 35 Ton Capacity***

Pony Motor option available*, 4th Axle Option Available

*FET Additional*

Delivery charges may apply

SPECS:
- Capacity: 55 tons in 12a length (GAWR and tire ratings determine legal payloads)
- Estimates Tare Weight (STANDARD PACKAGE): 20,100 lbs A+- 3%
- Overall: 8a 6a width x 52a8a length
- Clear deck length: 25a, (flat deck design)
- Deck height under full load: 22a (ground clearance 6a)
- 50a nominal loaded 5th wheel height (4 ride height positions)
- Rear bogie height: 41a
GOOSENECK DESIGN
- Hydraulic, detachable with 9a cylinders. non-ground bearing, set up for wet line
- Adjustable ride height features 4-position mechanical lock for separate deck and fifth wheel height control
- Air locking pin
- 102a swing radius
DECK DESIGN
- Main longitudinal members fabricated with 100 KSI yield steel flanges with 50 KSI yield webs
- Level deck design
- 10a I-beam crossmember on 24a centers with 4a stub cross members on 12a centers outer bay
- 1 1/2a nominal apitong
- Front of deck approach ramp with traction cleats
- Lockable toolbox in front of deck
- Removable swing-type outriggers (extends trailer width 2a) BOGIE DESIGN
- Fixed deck-to-bogie connection with front bogie ramp
- V-style boom trough
- Recessed load bearing bolsters between axles and behind last axle
- Heavy-duty V-style rear bumper
- Available fourth flip axle setup
- Ultra low bucket well
AXLES
- (3) Heavy-duty axles with 54 1/2a spread
- 25,000 lbs nominal capacity per axle (GAWR determined by suspension type, brakes, tires and other components)
- Tapered spindle axles
BRAKES
- 16 1/2a x 7a
- Heavy-duty brake drums, outboard mount
- Automatic slack adjusters
- Type 30/30 parking brakes on (2) axles
HUBS
- Hub-piloted 10-stud mount
- Outboard cast drums
WHEELS/TIRES
- (12) Steel disc wheels 8.25 x 22.5 with 275/70R22.5 H-ply tires (Aluminum available)
SUSPENSION
- Unitized heavy duty 25,000 lbs, air-ride suspension with automatic and manual controls
- 3rd axle air lift
- Suspension override prevention straps on all axles
ELECTRICAL SYSTEM
- Fully sealed wiring harness with LED lights
- Marker lights and mid-turn signals
- (3) Oval stop, tail and turn lights per side on rear
PROTECTIVE COATING
- High quality 2-part black acrylic urethane
- High quality 2-part primer
- White blasted and cleaned prior to painting
LASH RINGS
- (8) Pair (16 total), bent D-ring
FLAG HOLDERS
- (2) Pair (4 total)
