2025 Dorsey COMBO FLATBED W/ FORKLIFT KIT Flatbed Trailer

CAPACITY - Standard Beam Pkg - 80,000 GVWR (60,000 in 10' Span)
OVERALL LENGTH - 45'
OVERALL WIDTH - 8'6"
KING PIN SETTING - 30" - Tapered Front
UPPER COUPLER PLATE - 1/4"
UPPER COUPLER HEIGHT - 48"
FRONT SKIRT - Steel
REAR SKIRT - Steel
BULKHEAD - Yes
MAIN FRAME - 26" Fab. - Pre Camber I-Beams - (80K Pkg)
SIDE RAILS - 6" Aluminum Extruded W/Double L Track
FLOOR SILLS - 4" Steel I-Beam 12" O.C. HD Pkg
FLOOR DECKING - 1-1/8" HD Aluminum W/2 Nailer Boards
WINCH TRACK - Double L Aluminum - Extruded Siderail C/S & R/S - Both Sides
TIE BAR D/S & C/S - Full Length Both Sides
WINCHES - 12
SUSPENSION - Air Ride - Hendrickson Intraax 23K - Fixed
SUSPENSION LOCATION - Set 66" to CL of Rear Axle to Rear of Trailer
AXLES - (2) 22.5K Capacity - Type 30 Chambers - Auto Slacks
AXLE SPACING - 49"
LANDING GEAR - Two Speed - Jost A500
ABS SYSTEM - Wabco ABS System 2S/1M
PARKING BRAKES - All Axles
TIRES - 11R 22.5 Firestone
WHEELS - Disc - Hub Piloted - 22.5 - Polished Alum. on 4 Outside / Steel Inside
ANTI SAIL MUD FLAPS - Behind Rear Axle
STAKE POCKETS - 24" O.C. Sides & 4 Across Front
Spool Triangular Shaped
RUB BAND ALUM. 3/8" x 3" - Aluminum - Recessed for DOT Tape
LIGHTS - Grote Ultra Blue Sealed Wiring Harness - 2 Micros Per Side & Mid Turn - 2/3/2 Rear
FORK LIFT KIT MODELS - Universal MT Lift Hauler - Moffet M55 & Princeton PB50 W/Folding Bumper
FORK GUIDES - 4' Forks Non-Tublar Guides
COUNTER BALANCE 45' = 1250 Lbs.
COUNTER BALANCE CLAUSE - MFG Only Responsible for Issues With Listed Forklift Models
PAINT - PPG Epoxy Primer & Acrylic Polyurethane - Shot Blasted
